Break up and cultivate soil with the compact Sun Joe TJ599E Electric Cultivator, featuring an adjustable shaft and four steel tilling blades for preparing seed beds, gardens, and flower beds.
Meet the TJ599E
Why It Stands Out
Compact cultivating path
Cultivates up to 6.3 inches wide and 6 inches deep for gardens, flower beds, and seed-bed preparation.
Four steel blades
Four 6.5-inch steel tilling blades rotate at a no-load speed of 300 RPM.
Adjustable comfort
The telescoping shaft adjusts from 46 to 53 inches, and the auxiliary handle angle can be repositioned.
Electric power
The 2.5-amp motor provides corded cultivating power without gas or oil.
Technical Specifications
| Specification | Details |
|---|---|
| Model | TJ599E |
| Product Type | Electric garden cultivator |
| Rated Voltage | 120V AC, 60 Hz |
| Motor | 2.5 amp |
| No-Load Speed | 300 RPM |
| Blades / Tines | 4 steel tilling blades; 6.5 in. tine length |
| Maximum Cultivating Width | 6.3 in. (16 cm) |
| Maximum Cultivating Depth | 6 in. (15 cm) |
| Telescoping Shaft | 46–53 in. (116.8–135 cm) |
| Start Type | Safety lock button + trigger switch |
| Cord Features | Polarized plug and extension cord restraint hook |
| Net Weight | 9.7 lb |
| Product Dimensions | 46.4 H × 10.25 W × 8.75 L in. |
| Product Manual | Download the TJ599E operator’s manual (PDF) |
| Warranty | 2-year manufacturer’s warranty |
What’s in the Box
- TJ599E electric cultivator housing
- Auxiliary handle
- Locking knob
- Manual with registration card
Assembly
- Disconnect the power. Keep the cultivator unplugged while assembling or adjusting parts.
- Attach the auxiliary handle. Snap the auxiliary handle onto the machine.
- Secure the handle. Insert the locking knob through the auxiliary handle and tighten it firmly.
- Set the handle angle. To reposition it, loosen the knob, move the handle, and tighten the knob again.
- Adjust the shaft. Press the slide-lock button, extend the tube to a comfortable length, and release the button to lock it. Confirm the tube is locked before use.
Getting Started
- Prepare the work area. Remove rocks, sticks, wires, and other objects, check for hidden utility hazards, and keep children, pets, and bystanders at least 25 feet away.
- Connect the cord securely. Use the onboard extension cord restraint hook with an outdoor-rated cord, then plug into a suitable GFCI-protected outlet.
- Start the cultivator. Hold the tool firmly with both hands, press the safety lock button, squeeze the trigger switch, and then release the safety lock button.
- Guide the tool lightly. Move slowly backward and let the cultivator crawl forward in a rocking motion, using repeated passes to work deeper without forcing the tines.
- Manage the cord. Work away from the outlet and keep the extension cord behind you and outside the cultivating path.
- Stop safely. Release the trigger switch, unplug the tool, and wait for the tines to stop completely before lifting, inspecting, adjusting, or cleaning it.
Maintenance, Care & Storage
- Switch off, unplug, and wait for the tines to stop completely. Allow the motor housing and gearbox to cool before handling.
- Wear protective gloves. After every use, remove soil, dirt, and foliage from the tines, driveshaft, tool surfaces, and vents with a brush or dry cloth.
- Spray or rub biodegradable oil onto the tines, and clean soiled grips with a damp cloth.
- Do not use cleaning fluids or solvents, and do not spray the unit with water or pressurized water.
- Inspect the machine for worn or damaged parts, loose nuts, bolts, or screws, and missing or damaged safety labels and guards.
- Store indoors in a dry, high, or locked location out of children’s reach.
Troubleshooting
The cultivator stops during use
Possible Causes
- The unit is not fully assembled.
- The extension cord is not suitable, damaged, or too long.
- The startup sequence is not being followed correctly.
Solutions
- For your safety, please release the trigger and unplug the unit before performing any checks.
- Make sure the unit is fully assembled and that all handle knobs are securely tightened.
- Confirm that you are using an outdoor-rated extension cord. Inspect the extension cord for any cuts, damage, or loose connections, and make sure it does not exceed 100 feet in length.
- If your extension cord is 50 feet or shorter, verify that it is 14 AWG.
- To start the unit, press and hold the safety lock button, then squeeze the trigger switch while continuing to hold the safety lock button.
- If the unit starts after completing these checks, the issue has been resolved. If the unit still does not start, we can help you check your unit's warranty eligibility and assist you with the warranty claim process if applicable.
The cultivator is difficult to guide or will not dig deeper
Possible Causes
- The soil is extremely hard or resistant.
- The tool is being forced too deeply in one pass.
Solutions
- Remove surface obstructions and use light pressure.
- Work slowly backward and forward in repeated passes, and do not use the unit in extremely hard soil.
The cultivator vibrates abnormally
Possible Causes
- Debris is trapped around the tines.
- Hardware is loose or a component is damaged.
Solutions
- Stop immediately, unplug the unit, wait for the tines to stop, and remove trapped debris.
- Check for loose hardware or visible damage. Do not use the cultivator if damage is found or vibration continues; contact Shop Joe Customer Support.
Video Guide
Watch this official guide for a visual overview of the Sun Joe TJ599E Electric Cultivator.
If the video does not load, watch the TJ599E video guide on YouTube.
Frequently Asked Questions
What is the TJ599E designed to do?
It is intended for breaking up and cultivating coarse soil and mixing in fertilizer, peat, or compost in domestic gardens. It can also prepare seed beds and flower beds and dig small holes for saplings or potted plants.
How wide and deep can it cultivate?
The maximum cultivating width is 6.3 inches and the maximum cultivating depth is 6 inches.
Can I use it in rain or wet soil?
No. Do not use the cultivator in rain, damp, or wet locations, and do not touch the tool or plug with wet hands or while standing in water.
What extension cord should I use?
Use an outdoor-rated UL-, CSA-, or ETL-listed polarized extension cord. Use 16 AWG for a cord up to 50 ft or 14 AWG for a cord over 50 ft and up to 100 ft. Do not use a cord longer than 100 ft.
Where are the model and serial numbers?
The model and serial numbers are on the decal located on the housing or handle of the unit.
